Jacket: 100% Polyester high tenacity yarn
Lining: High quality EPDM, resistant to oil and fuel.
External Coating: polyurethane coated, increased the abrasion resistance and reduced the water absorption.
Standard Length: 15m (50ft), 30m (100ft)
Features: High abrasion resistance, UV resistance, Oil resistance, High-low temperature resistance.
Color: Grey
I.D. | Service Pressure | Minimum Burst Pressure | |||
inch | mm | psi | bar | psi | bar |
2” | 50 | 250 | 17 | 750 | 51 |
2 1/2” | 65 | 250 | 17 | 750 | 51 |
3” | 75 | 220 | 15 | 660 | 45 |
4” | 102 | 220 | 15 | 660 | 45 |
5” | 127 | 150 | 10 | 450 | 30 |
6” | 152 | 150 | 10 | 450 | 30 |
