Tube: NR+BR
Reinforcement: High tensile textile cord.
Cover: NR+SBR
Colour:Black
Temperature: -20℃ (-4℉)to +80℃ (+176℉)
Application: Delivery quartz and metal sand, polishing, ridding rust on metal surface and spraying cement.
I.D. | W.P. | B.P. | Length | ||||
mm | inch | psi | bar | psi | bar | ft | m |
19 | 3/4" | 170 | 12 | 525 | 36 | 200 | 61 |
25 | 1' | 170 | 12 | 525 | 36 | 500 | 61 |
32 | 1-1/4" | 170 | 12 | 525 | 36 | 200 | 61 |
38 | 1-1/2" | 170 | 12 | 525 | 36 | 200 | 61 |
51 | 2" | 170 | 12 | 525 | 36 | 200 | 61 |
64 | 2-1/2" | 170 | 12 | 525 | 36 | 200 | 61 |
76 | 3" | 170 | 12 | 525 | 36 | 200 | 61 |
Note: Specifications, pressures, colors, etc, can be customized according to requirements
