Tube: UHMWPE+EPDM
Reinforcement: High-strength spiral textile cord with helix steel wire
Cover: EPDM
Colour：Blue/Green/Black,etc
Safety factor：3:1
Temperature: -40℃ （-40℉）to +90℃ （+194℉）
Application: Used for transporting corrosive media such as strong acids and alkalis, mainly used in industries such as new energy, food, pharmaceuticals, etc
| I.D. | W.P. | B.P. | Length | ||||
| mm | inch | psi | bar | psi | bar | ft | m |
| 19 | 3/4" | 150 | 10 | 450 | 30 | 200 | 61 |
| 25 | 1" | 150 | 10 | 450 | 30 | 200 | 61 |
| 32 | 1-1/4" | 150 | 10 | 450 | 30 | 200 | 61 |
| 38 | 1-1/2" | 150 | 10 | 450 | 30 | 200 | 61 |
| 51 | 2" | 150 | 10 | 450 | 30 | 200 | 61.0 |
| 64 | 2-1/2" | 150 | 10 | 450 | 30 | 200 | 61 |
| 76 | 3" | 150 | 10 | 450 | 30 | 200 | 61.0 |
| 102 | 4" | 150 | 10 | 450 | 30 | 200 | 61 |
| 152 | 6" | 150 | 10 | 450 | 30 | 100 | 30.5 |
Note: Specifications, pressures, colors, etc, can be customized according to requirements
Tube: UHMWPE+EPDM
Reinforcement: High-strength spiral textile cord with helix steel wire
Cover: EPDM
Colour：Blue/Green/Black,etc
Safety factor：3:1
Temperature: -40℃ （-40℉）to +90℃ （+194℉）
Application: Used for transporting corrosive media such as strong acids and alkalis, mainly used in industries such as new energy, food, pharmaceuticals, etc
| I.D. | W.P. | B.P. | Length | ||||
| mm | inch | psi | bar | psi | bar | ft | m |
| 19 | 3/4" | 150 | 10 | 450 | 30 | 200 | 61 |
| 25 | 1" | 150 | 10 | 450 | 30 | 200 | 61 |
| 32 | 1-1/4" | 150 | 10 | 450 | 30 | 200 | 61 |
| 38 | 1-1/2" | 150 | 10 | 450 | 30 | 200 | 61 |
| 51 | 2" | 150 | 10 | 450 | 30 | 200 | 61.0 |
| 64 | 2-1/2" | 150 | 10 | 450 | 30 | 200 | 61 |
| 76 | 3" | 150 | 10 | 450 | 30 | 200 | 61.0 |
| 102 | 4" | 150 | 10 | 450 | 30 | 200 | 61 |
| 152 | 6" | 150 | 10 | 450 | 30 | 100 | 30.5 |
Note: Specifications, pressures, colors, etc, can be customized according to requirements
